GARR GARR 08110

GARR 195M 3/8 Ball Nose Center Cutting Stub Length Double End End Mill, 3/8 in Dia Cutter, 1/2 in Length of Cut, 4 Flutes, 3/8 in Dia Shank, 2-1/2 in OAL, Uncoated

UNSPSC: 27112803
Manufacturer PN: 195M 3/8
$45.92 EA
Factory Order
Estimated to ship in 7 days
QTY:


GARR End Mill, Ball Nose Center Cutting Stub Length Double End, Series: 195M, 3/8 in Diameter Cutter, 2-1/2 in Overall Length, 1/2 in Length of Cut, 4 Flutes, Spiral Flute, 3/8 in Shank Diameter, Right Hand Cutting Direction, 30 deg Helix Angle, Submicron Solid Carbide, Uncoated

  • Features

  • Shorter flute length for rigidity
  • Ball radius tolerance +0.000 to 0.001 in (+0.000 to 0.025 mm)

Specifications

Type Ball Nose Center Cutting Stub Length Double End
Series 195M
Cutter Diameter 3/8 in
Overall Length 2-1/2 in
Length of Cut 1/2 in
Number of Flutes 4
Flute Type Spiral
Shank Diameter 3/8 in
Cutting Direction Right Hand
Helix Angle 30 deg
