Midland Industries MIDM 28240
Midland Industries 28240 90 deg Street Elbow, 3/8 in Nominal, MNPT x FNPT End Style, Brass
Invoice description:
Elbow St Elb 3/8in Mip X Fip 1200psi Fgd Midland Industries 28240 90 Deg Street Elbow, 3/8 In Nominal, Mnpt X Fnpt End Style, Brass
Factory Order
Midland Industries Street Elbow, Fitting/Connector Type: 90 deg Elbow, 3/8 in Nominal, MNPT x FNPT, 1200 psi, Forged, Brass, -65 to 250 deg F, 0.72 x 1.06 in
Features
- Fair resistance vibration
- Used with brass, bronze, copper, steel, aluminum and iron pipe
- /- 0.02 tolerance on all dimensions
- 3/8-18 thread size
- 0.93 in wrench flat
Specifications
ApplicationFor grease, fuels, LP and natural Gas (available on special order), refrigeration, instrumentation and hydraulic systems
Dimensions0.72 x 1.06 in
End StyleMNPT x FNPT
Fitting/Connector Type90 deg Elbow
MaterialBrass
Method of ManufactureForged
Nominal Size3/8 in
Pressure Rating1200 psi
Temperature Rating-65 to 250 deg F
Additional Information
Standards/ApprovalASA Certified|ASME Specified|SAE Approved
Country of OriginUS
