DeWALT PWRS PFM1411760

DeWALT Screw-Bolt PFM1411760 1-Piece Heavy Duty High Performance Screw Anchor, 3/4 in Dia, 5 in OAL, Hex Washer Head Drive, Carbon Steel, 2-1/2 in D Min Embedment

UPC: 075352305158
UNSPSC:
Manufacturer PN: PFM1411760
$123.82 BX
In stock (4)
QTY:


DeWALT Screw-Bolt Screw Anchor, 1-Piece Heavy Duty High Performance, 3/4 in Diameter, 5 in Overall Length, Hex Washer Head Drive, Carbon Steel, 2-1/2 in Minimum Embedment Depth, 3/4 in Drill, Zinc Plated, Applicable Materials: Brick Masonry, Concrete Over Steel Deck, Grouted Concrete Masonry, Lightweight Concrete and Normal Weight Concrete, 43/64 in H Head

  • Features

  • Designed for standard ANSI tolerance drill bits
  • Low installation torque in concrete and masonry
  • Ratchet teeth on underside of hex washer head lock against the fixture
  • Fully removable and reinstallable in same hole
  • Diameter, length and identifying marking stamped on head of each anchor
  • Patented thread design offers toughened threads for tapping high strength concrete
  • Universal product for concrete and grouted/solid masonry
  • Can be installed closer to a free edge than traditional expansion anchors
  • Fast installation with powered impact wrench, but can also be installed manually
  • 1-piece, finished head design
ApplicationRacking, Shelving and Material Handling, Barriers, Guards and Temporary Support, Retrofits, Repairs and Maintenance, Cracked and Uncracked Concrete, Support Ledgers and Sill Plate Attachments, Glazing and Window Attachments, Fencing and Railing and Seismic and Wind Loading
