Dixon DIXV 300-D-AL

Dixon 300-D-AL Type D Cam and Groove Coupler, 3 in Nominal, Female Coupler x FNPT End Style, Aluminum

Invoice description: Coupler Female 3"

UNSPSC: 40141734

Manufacturer PN: 300-D-AL

^$63.31 EA

Factory Order
Estimated to ship in 7 days

enlarge

Product Overview

Dixon Cam and Groove Coupler, Type D, Coupling Fitting/Connector, 3 in Nominal, Female Coupler x FNPT End Style, 3-11/16 in Length, 125 psi Pressure, Aluminum

Features
10-3/32 in open across cam arm
Precision machined to rigid tolerances
Stainless pins will not rust or bind, providing great strength and safety
Recess holds gasket firmly in place - ensures proper placement
Long shank design allows proper banding, thus eliminating the major cause of hose damage
Buna-N gaskets
Durable stainless steel cam arm pins
Produced to interchange with all product produced to commercial item description A-A-59326D
Under no circumstances should cam and groove couplings be used for compressed air or steam service!
Pressure rating recommendations are based on the use of mating Dixon fittings at ambient temperature 70 deg F with a standard seal installed
