GARR GARR 02687
GARR 02687 870MA Center Cutting Stub Length Square End Mill, 20 mm Dia Cutter, 25 mm Length of Cut, 4 Flutes, 20 mm Dia Shank, 75 mm OAL, TiAlN Coated
Factory Order
GARR End Mill, Center Cutting Stub Length Square End, Series: 870MA, 20 mm Cutter Dia, 75 mm Overall Length, 25 mm Length of Cut, 4 Flutes, Helix Flute, 20 mm Shank Dia, Right Hand Cutting, 30 deg Helix Angle, Submicron Solid Carbide, TiAlN Coated
Features
- Shorter flute length for rigidity
- Extremely versatile
- Up to 40% faster than uncoated
Specifications
ApplicationDry or Semi-Dry Machining
Cutter Diameter20 mm
Cutting DirectionRight Hand
FinishTiAlN Coated
Flute TypeHelix
Helix Angle30 deg
Length of Cut25 mm
MaterialSubmicron Solid Carbide
Number of Flutes4
Overall Length75 mm
Series870MA
Shank Diameter20 mm
TypeCenter Cutting Stub Length Square End
Specification Sheet
