Fullerton FULLT 15615
Fullerton 15615 1505 Dominator Single End Standard Length Double Margin Drill, #7 Drill - Wire, 0.201 in Drill - Decimal Inch, Round Shank, 5XD D Cutting, 2 Flutes
Invoice description:
#7 (.2010) Drill Carb 1.5" Lof 3"oal Coated
Factory Order
Fullerton Double Margin Drill, Dominator Single End Standard Length, #7 Drill Size - Wire, 0.201 in Drill Size - Decimal Inch, 3 in Overall Length, 5XD Cutting Depth, 2 Flutes, Right Spiral Flute, 1-1/2 in Flute Length, 1/4 in Shank, Round Shank, 144 deg Point, Notched Point, Right Hand Cutting, Dura-Carb Cutting Edge, Dura-Carb, FC7 Coated, Applicable Materials: Steel, Stainless Steel, Superalloy and Titanium
Features
- +0.0000 to 0.0005 in/+0.000 to 0.013 mm shank diameter tolerance
- +0.0000 to 0.0005 in/+0.000 to 0.013 mm cutter diameter tolerance
- 30 deg helix
Specifications
Applicable MaterialsSteel, Stainless Steel, Superalloy and Titanium
Cutting Depth5XD
Cutting DirectionRight Hand
Cutting Edge MaterialDura-Carb
Drill Size - Decimal Inch0.201 in
Drill Size - Wire#7
FinishFC7 Coated
Flute Length1-1/2 in
Flute TypeRight Spiral
MaterialDura-Carb
Number of Flutes2
Overall Length3 in
Point Angle144 deg
Point TypeNotched
Series1505
Shank Size1/4 in
Shank TypeRound
TypeDominator Single End Standard Length
Additional Information
Standards/ApprovalISO-9001:2008
Country of OriginUS
