Iscar ISCAR 5606635

Iscar 5606635 HELI2000 Milling Insert, HM90 APCT Insert, 100308 Insert, Carbide, Manufacturers Grade: IC808, Parallelogram Shape, Material Grade: H, K, M, P, S

Invoice description: Hm90 Apct 100308-hp Ic80 8

UNSPSC: 23242107

Manufacturer PN: 5606635

^$37.89 EA

Factory Order
Estimated to ship in 14 days

enlarge

Product Overview

Iscar Milling Insert, Series: HELI2000, HM90 APCT Insert, 100308 Insert, Parallelogram Shape, 3.53 mm Thickness, 6.8 mm Width, 11.46 mm Length, HP Chipbreaker, 0.8 mm Corner Radius, Positive Rake, 11 deg Lead Angle, Manufacturers Grade: IC808, ISO Code: HM90 APCT 100308-HP IC808, Carbide, PVD-TiAlN/AlTiN+TiN Coated, Material Grade: H, K, M, P, S, Steel, Stainless Steel Ferritic and Martensitic, Stainless Steel Austenitic and Duplex, Cast Iron, High Temperature Alloys, Hard Steel and Hardened Cast Iron Material Application

Specifications

ApplicationCountersinking, Facing, Rampdown, Shouldering, Slotting, Slanted Shoulder and Chamfer

ChipbreakerHP

Corner Radius0.8 mm

FinishPVD-TiAlN/AlTiN+TiN Coated

Insert Size100308

Insert StyleHM90 APCT

ISO CodeHM90 APCT 100308-HP IC808

Lead Angle11 deg

Length11.46 mm

Manufacturers GradeIC808

MaterialCarbide

Material ApplicationSteel, Stainless Steel Ferritic and Martensitic, Stainless Steel Austenitic and Duplex, Cast Iron, High Temperature Alloys, Hard Steel and Hardened Cast Iron

Material GradeH, K, M, P, S

RakePositive

SeriesHELI2000

ShapeParallelogram

Thickness3.53 mm

Width6.8 mm
