Iscar ISCAR 6403832
Iscar 6403832 PICCOCUT Boring Bar, 6 mm Dia Min Bore, 24 mm Max Bore Depth, 40 mm OAL, Solid Carbide
Invoice description:
Picco R 050.6-25 Ic908
Factory Order
Iscar Boring Bar, Series: PICCOCUT, 6 mm Minimum Bore Dia, 24 mm Maximum Bore Depth, 40 mm Overall Length, 6 mm Shank Dia, Right Hand Cutting, Solid Carbide, PVD Coated, 2.3 mm Width Offset
Features
- IC908 Grade - A hard, fine grain substrate with excellent chipping resistance, combined with a TiAlN PVD coating
- Provides high wear and oxidation resistance
- Recommended for a very wide range of materials applications and machining conditions
Specifications
ApplicationChamfering, Internal Turning, Internal Boring and Profiling
Cutting DirectionRight Hand
FinishPVD Coated
MaterialSolid Carbide
Maximum Bore Depth24 mm
Minimum Bore Diameter6 mm
Overall Length40 mm
SeriesPICCOCUT
Shank Diameter6 mm
Width Offset2.3 mm
Additional Information
Country of OriginDE
