SGS SGS 34309
SGS 34309 43CB Corner Radius Fractional High Performance Chip Breaker End Mill, 1 in Dia Cutter, 2 in Length of Cut, 3 Flutes, 1 in Dia Shank, 4-1/2 in OAL, TB Coated
Invoice description:
End Mill 1" S-carb Tib
UPC: 691781343099
UNSPSC:
23242511
Manufacturer PN: 34309
$677.64 EA
Factory OrderEstimated to ship in 14 days
SGS End Mill, Corner Radius Fractional High Performance Chip Breaker, Series: 43CB, 1 in Cutter Dia, 4-1/2 in Overall Length, 2 in Length of Cut, 3 Flutes, Spiral Flute, 1 in Shank Dia, Right Hand Cutting, 38 deg Helix Angle, Straight Shank, 2-1/2 in Shank Length, Solid Carbide, TB Coated
Features
- Circular land allows for increased control at various speed and feed rates and reduces chatter
- Symmetrical end gashing for excellent balance at high speeds and aggressive plunging capability
- Open fluting for deep slotting and profiling
- Chip breakers reduce machine loads up to 15% for increased roughing feed rate capability
- Suitable for non-ferrous and plastics/composites
- Recommended for materials 150 Bhn (7 HRc)
Specifications
ApplicationAerospace, Automotive, Castings and Foundries, General Engineering, Medical, Mold and Die and Power Generation
Cutter Diameter1 in
Cutting DirectionRight Hand
FinishTB Coated
Flute TypeSpiral
Helix Angle38 deg
Length of Cut2 in
MaterialSolid Carbide
Number of Flutes3
Overall Length4-1/2 in
Series43CB
Shank Diameter1 in
Shank Length2-1/2 in
Shank TypeStraight
TypeCorner Radius Fractional High Performance Chip Breaker
Additional Information
Country of OriginUS
