Midland Industries MIDM 943213

Midland Industries 943213 Gas Ball Valve, 3/4 in Nominal, FIPS End Style, Forged Brass Body, Large Port, NBR Softgoods, Import

Invoice description: Valve Gas Ball 3/4in Fip S 400 Psi Wog Midland Industries 943213 Gas Ball Valve, 3/4 In Nominal, Fips End Style, Forged Brass Body, Standard Port, Nbr Softgoods, Import

UNSPSC: 40141607
Manufacturer PN: 943213
$23.72 EA
Factory Order
Estimated to ship in 7 days
QTY:


Midland Industries Gas Ball Valve, 3/4 in Nominal, FIPS End Style, 400 psi WOG Pressure, Large Port, Solid Polished Chrome Forged Brass Ball, Forged Brass Body, Brass Stem/PTFE Ball Seat Trim, NBR Softgoods, 1.57 in H x 2.48 in W Dimensions, Import

  • Features

  • Deeper thread connections, smooth quarter-turn
  • Bottom entry
  • Blow-out proof design
  • Double viton o-rings stem seals and teflon seats for durability
  • Forged construction for greater strength
  • Larger ports for increased flow capacity
  • Red reversible handle
  • Steel butterfly, UNI 5771 steel screw
  • NBR O-Ring

Specifications

ApplicationNatural, Manufactured, Mixed Liquefied, Petroleum and LP Gas-Air Mixtures
Ball MaterialSolid Polished Chrome Forged Brass
Body MaterialForged Brass
Dimensions1.57 in H x 2.48 in W
Domestic/ImportImport
End StyleFIPS
Nominal Size3/4 in
Port TypeLarge
Pressure Rating400 psi WOG
Softgoods MaterialNBR
Trim MaterialBrass Stem/PTFE Ball Seat

Additional Information

Standards/ApprovalCSA AGA 3.88 5 PSIG|UL 842|UL 258|UL 125|ANSI Z21.15|C.G.A. 9.1-M81|9.2-M88|A.G.A.3-8|C.G.A. CR91-002
Country of OriginIT
