SGS®
SGS® 31533 15S Double End Fractional Stub Length Square End End Mill, 5/16 in Dia Cutter, 1/2 in Length of Cut, 2 Flutes, 5/16 in Dia Shank, 2-1/2 in OAL, Uncoated

Item # SGS 31533
UM: EA
Price: $34.49
Availability: In stock (7)
QTY:


SGS® End Mill, Double End Fractional Stub Length Square End, Series: 15S, 5/16 in Diameter Cutter, 2-1/2 in Overall Length, 1/2 in Length of Cut, 2 Flutes, Spiral Flute, 5/16 in Shank Diameter, Right Hand Cutting Direction, 30 deg Helix Angle, Straight Shank, 2 in Shank Length, Micrograin Solid Carbide, Uncoated

  • Specifications
  • Application: Aerospace, Automotive, Castings and Foundries, General Engineering, Medical, Mold and Die and Power Generation
  • Type: Double End Fractional Stub Length Square End
  • Series: 15S
  • Cutter Diameter: 5/16 in
  • Overall Length: 2-1/2 in
  • Length of Cut: 1/2 in
  • Number of Flutes: 2
  • Flute Type: Spiral
  • Shank Diameter: 5/16 in
  • Cutting Direction: Right Hand
  • Helix Angle: 30 deg
  • Shank Type: Straight
  • Shank Length: 2 in
  • Material: Micrograin Solid Carbide
  • Finish: Uncoated
  • UNSPSC: 23242511
  • Manufacturer Part Number: 8065368
  • UPC: 691781315331
