Harvey Tool HARV 25508-C3
Harvey Tool 25508-C3 Center Cut Flat Bottom Long Reach Counterbore, 0.1250 in Dia Bore, 2-1/2 in OAL, Right Hand Cutting
Invoice description:
Counter Bore 1/8x1/2x1/8 X2-1/2 Sq 4fl Flt Btm
Manufacturer PN: 25508-C3
$72.00 EA
Factory OrderEstimated to ship in 7 days
Harvey Tool, 25508-C3, Counterbore, Center Cut Flat Bottom Long Reach, 0.1250 in Bore, 2-1/2 in Overall Length, 1/8 in Shank Diameter, 4 Flutes, Helical Flute, Right Hand Cutting Direction, Solid Carbide, AlTiN
Features
- Undersized neck to avoid heeling
- Flat Bottom (No Dish) design allows spot facing or counterboring on irregular surfaces
- Ground with full cylidrical margin (not side cutting)
- Applicable Materials are Non-Ferrous Metal, Cast Iron, Steel, Stainless Steel, Composites
- Cutter Diameter 0.1250 in (1/8)
- Flute Length 0.5000 in (1/2)
- Overall Reach 1.0000 in (1)
- Profile Square
Specifications
ApplicationCastings, Rounded Parts, Concaved or Drafted Surfaces , Flat bottom reaming or straightening misaligned holes
Bore Diameter0.1250 in
Cutting DirectionRight Hand
FinishAlTiN
Flute TypeHelical
MaterialSolid Carbide
Number of Flutes4
Overall Length2-1/2 in
Shank Diameter1/8 in
TypeCenter Cut Flat Bottom Long Reach
Additional Information
Standards/ApprovalPROP65: This product contains chemicals known to the State of California to cause cancer
Country of OriginUS
