Harvey Tool HARV 57028
Harvey Tool 57028 Back Deburring Mill, 0.028 in Dia Cutter Head, 0.0200 in W Flat, 2 in OAL, Cylindrical Shank, 0.0029 in W Chamfer
Invoice description:
Dem .028x.25x45 Deg 3fl Dem .028x.25x45 Deg 3fl
Manufacturer PN: 57028
$118.04 EA
Factory OrderEstimated to ship in 7 days
Harvey Tool, 57028, Back Deburring Mill, 0.028 in Diameter Cutter Head, 90 deg Included Angle, 0.0029 in Chamfer Width, 0.0200 in Flat Width, 2 in Overall Length, Cylindrical Shank, 1/8 in Shank Diameter, Right Hand Cutting Direction, Chamfer Threaded End Style, 3 Flutes, Solid Carbide, Uncoated
Features
- Slightly undersized to fit in common hole sizes
- Design has smaller radial projection than double angle shank cutters and back chamfer cutters, which results in increased neck diameter and improved strength
- Left hand shear flute / right hand cut evacuates chip away from part
- Applicable Materials are Aluminum, Cast Iron, Steel, Stainless Steel, Wood, Composites
- Axial Length Of Cut 0.0029 in
- Neck Length 0.2500 in (1/4)
- Chamfer Center Length 0.0215 in
Specifications
ApplicationDeburring on backside of small holes and tight pockets
Chamfer Width0.0029 in
Cutter Head Diameter0.028 in
Cutting DirectionRight Hand
End StyleChamfer Threaded
FinishUncoated
Flat Width0.0200 in
Included Angle90 deg
MaterialSolid Carbide
Number of Flutes3
Overall Length2 in
Shank Diameter1/8 in
Shank TypeCylindrical
Additional Information
Standards/ApprovalPROP65: This product contains chemicals known to the State of California to cause cancer
Country of OriginUS
