YG-1 YG1 T5707C
YG-1 T5707C T5-C Combo Multi-Purpose Single End Spiral Flute Tap, Right Hand Cutting, M20x2.5 Thread, D7 Thread Limit, Semi-Bottoming Chamfer, Right Hand Flute Direction, 4 Flutes, TiCN Coated, HSS-EX
Invoice description:
M20 X 2.50 4 Flt Spiral Fltd Combo Tap
Factory Order
YG-1 Spiral Flute Tap, Combo Multi-Purpose Single End, Measurement System: Metric, M20x2.5, Semi-Bottoming Chamfer, 4 Flutes, HSS-EX, TiCN Coated, Right Hand Cutting, 0.787 in Thread Length, 4.47 in Overall Length, 5/8 in Shank Dia, 3.683 in Shank Length, Right Hand Flute Direction, D7 Thread Limit, Steel and Stainless Steel Material Application
Features
- Reduces tap breakage, ensures accurate thread depth
- Eliminates loose threads due to tap overfeeding
- Improves thread quality and chip evacuation
- Eliminates "bird nests" around tap shank
Specifications
ApplicationFor multi-purpose
Chamfer TypeSemi-Bottoming
Cutting DirectionRight Hand
Finish/CoatingTiCN Coated
Flute DirectionRight Hand
MaterialHSS-EX
Material ApplicationSteel and Stainless Steel
Measurement SystemMetric
Number of Flutes4
Overall Length4.47 in
SeriesT5-C
Shank Diameter5/8 in
Shank Length3.683 in
Thread Length0.787 in
Thread LimitD7
Thread SizeM20x2.5
TypeCombo Multi-Purpose Single End
Additional Information
Standards/ApprovalANSI Specified
