Edison BUSS ATC-25

Edison ATC-25 Fast Acting Fast Blow Automotive Fuse, 25 A, 32 VDC, 1 kA

UPC: 051712703277
Pack Size: 5
UNSPSC:
Manufacturer PN: ATC-25
$2.14 EA
In stock (80)
QTY:


Edison Automotive Fuse, Fast Acting Fast Blow, Series: ATC, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Non-Rejection, 25 A, 32 VDC, 1 kA Interrupt, 0.75 to 120 s Response, Blade Terminal, Holder Mount, Single Element, 0.76 in Width, 0.207 in Depth, Plastic, Clear

  • Features

  • Industry standard color coding for quick identification of amperage rating
  • Tin plated zinc terminals for corrosion resistance and enhanced conductivity
  • Wide -40 to 100 deg C operating temperature range meets the needs of extreme environments
  • Lead free and halogen free
  • Test points on specific part/package numbers may speed up circuit troubleshooting
  • UL recognized for use in low voltage control circuits

Specifications

ApplicationLow Voltage Control Circuits and Automotive Applications
Amperage Rating25 A
ColorClear
Depth0.207 in
ElementSingle
Indicating/Non-IndicatingNon-Indicating
Interrupt Rating1 kA
MaterialPlastic
Mounting TypeHolder
Rejection/Non-RejectionNon-Rejection
Response Time0.75 to 120 s
SeriesATC
Terminal TypeBlade
TypeFast Acting Fast Blow
Voltage Rating32 VDC
Width0.76 in
