Bussmann BUSS ATC-3

Bussmann ATC-3 Standard Fast Acting Fuse, 3 A, 32 VDC, 1 kA Interrupt

UPC: 051712703215
Pack Size: 5
UNSPSC:
Manufacturer PN: ATC-3
$7.76 EA
Factory Order
Estimated to ship in 30 days
QTY:


Bussmann Fuse, Standard Fast Acting, Series: ATC, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Non-Rejection, 3 A, 32 VDC, 1 kA Interrupt, Blade Terminal, Holder Mount, Single Element, 0.76 in W, 0.207 in D, Plastic, Violet

  • Features

  • Industry standard color coding for quick identification of amperage rating
  • Tin plated zinc terminals for corrosion resistance and enhanced conductivity
  • Wide -40 to 100 deg C operating temperature range meets the needs of extreme environments
  • Lead free and halogen free
  • Test points on specific part/package numbers may speed up circuit troubleshooting
  • UL recognized for use in low voltage control circuits

Specifications

ApplicationAutomotive and Low Voltage Control Circuit Applications
Amperage Rating3 A
ColorViolet
Depth0.207 in
ElementSingle
Indicating/Non-IndicatingNon-Indicating
Interrupt Rating1 kA
MaterialPlastic
Mounting TypeHolder
Rejection/Non-RejectionNon-Rejection
SeriesATC
Terminal TypeBlade
TypeStandard Fast Acting
Voltage Rating32 VDC
Width0.76 in
