Starrett LSS S78MXTCZ
Starrett S78MXTCZ 78MXT Global Series Mechanical Bore Gage Set, 6 to 10 mm, Graduations: 0.005 mm, 18 to 58 mm D Probe, Tungsten Carbide
Invoice description:
Micrometer Sets Extended T Ravel With Cases
Factory Order
Starrett Bore Gage Set, Mechanical, Series: 78MXT Global Series, 6 to 10 mm, 0.004 mm Accuracy, Graduations: 0.005 mm, 0.005 mm Resolution, 18 to 58 mm Probe Depth, Tungsten Carbide
Features
- Wide measurement range without changing anvils
- Tungsten carbide measuring faces on all 3-point heads above 1/2 in (12.5 mm)
- Ratchet stop ensures consistent measurements
- Self-centering contacts for true readings
- Blind bore measuring capability above 1/2 in (12.5 mm) diameter
- Extensions available up to 6 in (150mm) for deep hole measuring
- 2 heads and 1 ring
- 3 point contact
Specifications
Accuracy0.004 mm
Graduations0.005 mm
MaterialTungsten Carbide
Measuring Range6 to 10 mm
Probe Depth18 to 58 mm
Resolution0.005 mm
Series78MXT Global Series
TypeMechanical
Additional Information
IncludesCase, Contacts, Instructions, Setting Ring and Wrenches
Country of OriginGB
