Starrett LSS S78XTFZ

Starrett S78XTFZ 78XT Global Series Mechanical Bore Gage Set, 2 to 4 in, Graduations: 0.00025 in, 3-1/16 to 4 in D Probe, Tungsten Carbide

UPC: 049659676846
UNSPSC: 41111600
Manufacturer PN: S78XTFZ
$7,977.98 EA
Factory Order
QTY:


Starrett Bore Gage Set, Mechanical, Series: 78XT Global Series, 2 to 4 in, 0.0002 in Accuracy, Graduations: 0.00025 in, 0.0002 in Resolution, 3-1/16 to 4 in Probe Depth, Tungsten Carbide

  • Features

  • Wide measurement range without changing anvils
  • Tungsten carbide measuring faces on all 3-point heads above 1/2 in (12.5 mm)
  • Ratchet stop ensures consistent measurements
  • Self-centering contacts for true readings
  • Blind bore measuring capability above 1/2 in (12.5 mm) diameter
  • Extensions available up to 6 in (150mm) for deep hole measuring
  • 3 heads and 2 rings
  • 3 point contact

Specifications

Accuracy0.0002 in
Graduations0.00025 in
MaterialTungsten Carbide
Measuring Range2 to 4 in
Probe Depth3-1/16 to 4 in
Resolution0.0002 in
Series78XT Global Series
TypeMechanical
