Power Team SPX C53C

Power Team C53C C Series General Purpose High Quality Single Action Hydraulic Cylinder, 53 ton Capacity, 1-1/8 in Bore, 3-1/4 in L Stroke, 6-1/2 in H Retract, 1 in Dia Rod, 10061 psi Pressure

Invoice description: Cyl 5 Ton 31/4 Stroke Cyl 5 Ton 31/4 Stroke

UPC: 662536406925
UNSPSC: 27121602
Manufacturer PN: C53C
$751.72 EA
Factory Order
Estimated to ship in 7 days
QTY:


Power Team, C53C, Hydraulic Cylinder, General Purpose High Quality Single Action, Series: C Series, 53 ton Capacity, 1-1/8 in Bore, 3-1/4 in Stroke Length, 6-1/2 in H Retract, Surface Mounting, 3/4 in Port, 1 in Rod Diameter, 10061 psi Pressure, Steel Housing Material, 1-1/2 in OD Dimensions

  • Features

  • Solid steel cylinder body for durability
  • Base mounting holes standard on 5 through 55 ton cylinders
  • Rugged and high quality general-purpose cylinder
  • Aluminum bronze bearing reduces wear caused by off-center loads
  • Maximum sized springs speed piston return and increase spring life
  • Collar threads are standard on all C-series models, simplifying fixturing applications
  • Removable rubber boots protect collar threads during transport and storage
  • Chrome plated piston rod resists wear and corrosion
  • A 3/8 in NPTF female half coupler is standard

Specifications

ApplicationLifting and Pressing Applications
Bore Size1-1/8 in
Capacity53 ton
Dimensions1-1/2 in OD
Housing MaterialSteel
Mounting TypeSurface
Port Size3/4 in
Pressure Rating10061 psi
Retract6-1/2 in H
Rod Diameter1 in
SeriesC Series
Stroke Length3-1/4 in
TypeGeneral Purpose High Quality Single Action

Additional Information

Standards/ApprovalASME B30.1|CE Certified|ANSI
