PFERD PFE 23201
PFERD 21823201 Universal Line Premium Grade Indexable Turning Tool Holder, Radius End, Cylindrical - Radius End (Shape SC) Head, 1/4 in Dia Head, 1/2 in L of Cut, 1-11/16 in OAL, Single Cut
Invoice description:
Sc-51-sc 1/8"snk 1/4" Cy L Ball 1/8 Sk Bp
In stock
(30)
PFERD Indexable Turning Tool Holder, Premium Grade, Series: Universal Line, Radius End, 1/4 in Diameter Head, 1/2 in Length of Cut, 1-11/16 in Overall Length, Cylindrical - Radius End (Shape SC) Head Shape, Single Cut, 1/8 in Shank Diameter, 1-3/16 in Shank Length, Tungsten Carbide Head, Bright Head Coating, 48000 rpm Maximum, Applicable Materials: Cast Iron, Cast Steel, Non-Ferrous Metals, Steel and Stainless Steel, Industry Specification: SC-51
Features
- Good stock removal rate through optimum matching of tungsten carbide, geometry, cut and available coating
- Long service life
- Reduced wear on the power tool due to impact-free work without chatter marks, due to the high concentricity
- High surface quality
Specifications
ApplicationDeburring, Leveling, Milling Out, Cutting Out Holes, Surface Work and Work on Weld Seams
Applicable MaterialsCast Iron, Cast Steel, Non-Ferrous Metals, Steel and Stainless Steel
Cut TypeSingle
End TypeRadius
Head CoatingBright
Head Diameter1/4 in
Head MaterialTungsten Carbide
Head ShapeCylindrical - Radius End (Shape SC)
Industry SpecificationSC-51
Length of Cut1/2 in
Maximum Speed48000 rpm
Overall Length1-11/16 in
SeriesUniversal Line
Shank Diameter1/8 in
Shank Length1-3/16 in
TypePremium Grade
Additional Information
Standards/ApprovalPROP65: California to cause cancer. www.P65Warnings.ca.gov/product
Country of OriginDE
