Sandvik Coromant SANC 6532309
Sandvik Coromant 6532309 T-Max P 2-Sided Basic Shape Turning Insert, ANSI Code: RNMG 86 4325, RNMG Insert, Material Grade: K, P, 86 Insert, Round Shape, 25 Seat, Negative Rake, Neutral Cutting, For Use On Cast Iron and Steel, Carbide
In stock
(2)
Sandvik Coromant Turning Insert, 2-Sided Basic Shape, Series: T-Max P, RNMG Insert, 86 Insert, Round, 0.394 in Maximum Depth of Cut, 1 in Inscribed Circle, 3/8 in Thickness, 25 Seat, Negative Rake, NMG Chipbreaker, 1/2 in Corner Radius, 0.359 in Hole Dia, Manufacturers Grade: 4325, ANSI Code: RNMG 86 4325, ISO Code: RNMG 25 09 00 4325, 0 deg Relief Angle, Neutral Cutting, Carbide, CVD-TiCN+Al2O3+TiN Coated, Material Grade: K, P, For Use On: Cast Iron and Steel
Features
- Reliable and secure machining, even in roughing applications
- Possibility to optimize by using damped Silent Tools
- Excellent surface finish
Specifications
ApplicationMedium Applications
ANSI CodeRNMG 86 4325
ChipbreakerNMG
Corner Radius1/2 in
Cutting DirectionNeutral
FinishCVD-TiCN+Al2O3+TiN Coated
For Use OnCast Iron and Steel
Hole Diameter0.359 in
Inscribed Circle1 in
Insert Size86
Insert StyleRNMG
ISO CodeRNMG 25 09 00 4325
Manufacturers Grade4325
MaterialCarbide
Material GradeK, P
Maximum Depth of Cut0.394 in
RakeNegative
Relief Angle0 deg
Seat Size25
SeriesT-Max P
ShapeRound
Thickness3/8 in
Type2-Sided Basic Shape
